Atrium double focus. Sophisticated light for high rooms

The lighting tool for perfectly glare-free light from the ceiling

Show products

Atrium double focus in the application

Individualize Atrium double focus for your use case

With our “ERCO individual” service we offer you extensive options for the individualization of series products as well as support in the development of sophisticated special luminaires. In order to match Atrium double focus even more efficiently to your project requirements, further variants are available on request in addition to the series configuration. These include, for example:

  • Anti-glare cone: coated matt gold or matt champagne
  • Mounting ring: 10,000 further colors
  • Control: Lutron

Do you have further requirements with the product?

Please contact the consultant team in the following ERCO office:
{{strasse1}}
{{#strasse2}} {{strasse2}}
{{/strasse2}} {{ort}}
{{staat}}

Product features in detail

1

2

3

4

5

6

1

ERCO Spherolit lens

  • Light distributions: flood, wide flood or wallwash

2

ERCO LED-module

  • High-power LEDs: warm white (2700K or 3000K) or neutral white (3500K or 4000K)
  • Collimating lens made of optical polymer

3

Anti-glare cone

  • Optical cut-off 40° from horizontal
  • Black or matt silver coated

or

Anti-glare ring (double focus for sloping ceilings)

  • Cast aluminum or polymer, external white, internal black

4

Mounting ring

  • Covered mounting detail
  • Fixing for ceiling thicknesses of 1-25mm (size 3-4) or 1-30mm (size 5-10)
  • Polymer, white
  • For flush mounting: mounting ring to be ordered separately, fixing for ceiling thicknesses of 12.5–25mm

5

Housing

  • Cast aluminum, designed as heat sink
  • Rotatable through 360°
  • For inclined ceilings: 0°-30° tilt. Lockable angles of tilt and rotation

6

Control gear

  • Switchable, trailing edge dimmable or 0-10V dimmable

Trailing edge dimmable version:

  • Operation at 120V: Dimming with external dimmers possible

Atrium double focus: Light effect and planning aid

Ambient lighting produced by wide beam light distribution.

Lighting tool

Light distribution

Downloads

Request now: Atrium double focus for your next project

We will be happy to provide you with an offer, support you with sampling and be available to answer specific planning questions.

Your contact data:

The fields highlighted in red must be filled out correctly!

free of charge and without obligation

Your data will be handled confidentially. For further information see Data protection declaration.

Configure Atrium double focus
