Lighting interior spaces

Using light to divide rooms and accentuate architectural elements

Light can alter the appearance of a room or area without physically changing it. Light directs our view, influences perception and draws our attention to specific details. Light can be used to divide and interpret rooms in order to emphasise areas or establish continuity between the interior and exterior. Light distribution and illuminance have a decisive influence on how architecture is perceived.

Forming functional zones

Forming functional zones Forming functional zones Forming functional zones Forming functional zones Forming functional zones Forming functional zones

Light can be used to emphasise individual functional zones in an area, e.g. traffic areas, waiting areas, and exhibition areas. Zonal lighting with delineated beams of light visually separates one area from another. Different illuminance levels establish a perceptual hierarchy and direct the viewer’s gaze. The differentiation of light colours creates contrasts and emphasises individual zones.
Differentiated lighting of functional zones divide up an area and improve orientation. Areas of a space can be separated from each other using narrow beams of light and strong contrasts in brightness. Distinct contrasts between individual zones and their surroundings remove them from their spatial context. Large areas that on the whole are evenly illuminated can appear rather monotone if they are not divided up. Low general lighting provides the basis for adding lighting accents. Lighting control systems allow functional zones to be adapted to different uses.

Defining spatial borders

Floor illumination emphasises objects and pedestrian surfaces. Vertical spatial borders are emphasised by illuminating wall surfaces. Uniform light distribution emphasises the wall as a whole, whereas accentuating, grazing light gives the wall structure by adding patterns of light. Bright walls create a high level of diffuse light in the room.

Vertical illumination is used to shape the visual environment. Room surfaces can be differentiated using different levels of illuminance to indicate their importance. Uniform illumination of the surfaces emphasises them as an architectural feature. A decreasing level of brightness across a wall is not as effective as uniform wallwashing at defining room surfaces. Lighting effects using grazing light emphasise the surface textures and become the dominant feature. Indirect lighting of a ceiling creates diffuse light in the room with the lighting effect being influenced by the reflectance and colour of its surface.

Emphasising architectural features

Emphasising architectural features Emphasising architectural features Emphasising architectural features Emphasising architectural features


Wall structure

The illumination of architectural details draws attention away from the room as a whole towards individual components. Columns appear as silhouettes in front of an illuminated wall. Narrow-beam downlights emphasise theform of the columns. Grazing light accentuates individual elements or areas and brings out their form and surface texture.
Rooms can be given a visual structure by illuminating the architectural features. By using different levels of illuminance, different parts of a room can be placed in a visual hierarchy. Grazing light can cause highly three-dimensional features to cast strong shadows.
