Opton. The lighting tool for shop lighting

Flexible and low-cost illumination for salesrooms

Show products

Opton in the application

Individualize Opton for your use case

With our “ERCO individual” service we offer you extensive options for the individualization of series products as well as support in the development of sophisticated special luminaires. In order to match Opton even more efficiently to your project requirements, further variants are available on request in addition to the series configuration. These include, for example:

  • Housing: 10,000 further colors

Do you have further requirements with the product?

Please contact the consultant team in the following ERCO office:
{{strasse1}}
{{#strasse2}} {{strasse2}}
{{/strasse2}} {{ort}}
{{staat}}

Product features in detail

1

2

3

4

5

6

1

ERCO Spherolit lens

  • Light distributions: narrow spot, spot, flood, wide flood, extra wide flood, oval flood or wallwash
  • Oval flood adjustable through 90°

2

ERCO LED-module

  • High-power LEDs: warm white (2700K or 3000K) or neutral white (3500K or 4000K)
  • Collimating lens made of optical polymer

3

Light head

  • White (RAL9002), black or silver
  • Cast aluminum, powder-coated
  • 0°-90° tilt
  • Frame: polymer, black

4

Housing

  • White (RAL9002), black or silver
  • Polymer
  • Rotatable through 360° on adapter

5

Control gear

  • Trailing edge dimmable+On-board Dim
  • Dimming with external dimmers (trailing edge) possible and rotary control for brightness control on the luminaire

6

ERCO turning adapter for 2-circuit track

Opton: Light effect and planning aid

Lighting tool

Light distribution

Downloads

Request now: Opton for your next project

We will be happy to provide you with an offer, support you with sampling and be available to answer specific planning questions.

Your contact data:

The fields highlighted in red must be filled out correctly!

free of charge and without obligation

Your data will be handled confidentially. For further information see Data protection declaration.

Configure Opton
