Skim. Lighting design for any architecture

The low-cost recessed luminaire for office and general lighting

Show products

Special features of Skim
View product description

Suitable for office workstations

ERCO develops luminaires with the specifications of good glare control and high visual comfort. UGR values are used as support for purely norm-referenced lighting. With downlights though this should not be carried out using 'blanket' values, but should be implemented according to the individual arrangement of luminaires in the room.

Shallow recess depth

In compact installation situations, every millimetre is decisive with the recess depth of a luminaire. ERCO has thus developed special luminaires for shallow recess depths that guarantee very good quality of light even in very tight installation conditions.

Skim combines an attractive appearance with high quality of light and an excellent price-performance ratio. Ideal for offices, foyers and circulation zones as well as in retail, or the hotel industry. Several sizes, wattages and light distributions make Skim an attractive alternative to conventional luminaires. The lens system not only scores with a magical appearance, but also with high efficiency, uniformity and good visual comfort. Depending on the projected light distribution, Skim either provides particularly economical general lighting with large luminaire spacing or is ideal as standard-compliant task lighting.

Skim in the application

Wholegreen Bakery, Sydney. Architecture: Sarah Johnson / Lifesize, Sydney. Photography: Jackie Chan, Sydney.

Bec & Bridge, Melbourne. Architecture: George Livissianis. Photography: Jackie Chan, Sydney.

Nilco fishing company, Hirtshals. Architecture: Arkitektfirmaet Hovaldt Søren Andersen El-Raadgivning, Vrå. Photography: Johan Elm, Stockholm.

International Airport, Sydney. Lighting and electrical design: Aurecon Sydney, Sydney. Photographer: Jackie Chan, Sydney.

NK Kaffe & Tehandel, Stockholm. Lighting design: Oscar Nyström Lighting Design, Stockholm. Photography: Johan Elm, Stockholm.

Bory Mall shopping mall, Bratislava. Architecture: Massimiliano Fuksas, Rome. Photographer: Dirk Vogel, Dortmund

Engel & Völkers Market Centre, Madrid. Photographer: Frieder Blickle, Hamburg.

Ameron Hotel Speicherstadt, Hamburg. Architecture: Winking Froh Architekten, Berlin. Lighting design: team licht, Hamburg. Photographer: Frieder Blickle, Hamburg.

Individualise Skim for your use case

With our “ERCO individual” service we offer you extensive options for the individualisation of series products as well as support in the development of sophisticated special luminaires. In order to match Skim even more efficiently to your project requirements, further variants are available on request in addition to the series configuration. These include, for example:

Connection: 3- or 5-pole plug with connection cable (Wago or Wieland)
Ceiling channel system

Do you have further requirements with the product?

Please contact the consultant team in the following ERCO office:
{{strasse1}}
{{#strasse2}} {{strasse2}}
{{/strasse2}} {{ort}}
{{staat}}

Call an ERCO consultant: {{fon}}

Your contact partners worldwide

Product features in detail

1 ERCO lens system

Made of optical polymer
Light distributions: wide flood, extra wide flood or oval flood

2 ERCO LED-module

High-power LED: warm white (2700K or 3000K) or neutral white (3500K or 4000K)

3 Anti-glare cone

White (RAL9016) or black
Optical cut-off 30°
Polymer
With covered mounting detail

4 Housing

Cast aluminium, designed as heat sink
Folding spring fixing for ceiling thicknesses of up to 25mm (size 3) or 40mm (size 5)

5 Control gear

Switchable, phase dimmable, DALI dimmable or Casambi Bluetooth
Phase dimmable version: Dimming with external dimmers possible (trailing edge)

1 ERCO lens system

Made of optical polymer
Light distributions: wide flood, extra wide flood or oval flood

2 ERCO LED-module

High-power LED: warm white (2700K or 3000K) or neutral white (3500K or 4000K)

3 Anti-glare cone

White (RAL9016) or black
Optical cut-off 30°
Polymer
With covered mounting detail

4 Housing

Cast aluminium, designed as heat sink
Folding spring fixing for ceiling thicknesses of up to 25mm (size 3) or 40mm (size 5)

5 Control gear

Switchable, phase dimmable, DALI dimmable or Casambi Bluetooth
Phase dimmable version: Dimming with external dimmers possible (trailing edge)

Skim: Light effect and planning aid

Lighting tool

Light distribution

Ambient lighting produced by wide beam light distribution.

Lighting technology
Luminaire arrangement

Downlights

Wide beam, rotationally symmetrical light distribution for general lighting.

Light source
8W - 28W
790lm - 3690lm
Downlights

Downlights

For optimum general lighting, the luminaire spacing (d) between two Skim downlights may, as a rough guide, be up to 1.5 times the height (h) of the luminaire above the working plane.

Arrangement: d ≤ 1.5 x h

The wall offset should be half the luminaire spacing.

Arrangement: a = d / 2

Linear general lighting for spatial structuring and the illumination of zones and pathways.

Lighting technology
Luminaire arrangement

Downlights oval flood

Axially symmetrical light distribution for linear lighting.

Light source
8W - 28W
790lm - 3690lm
Downlights oval flood

Downlights oval flood

For uniform lighting with luminaires arranged in a line, the spacing (d) between two Skim downlights may be up to approximately 1.5 times the height (h) of the luminaire above the working plane.

Arrangement: d ≤ 1.5 x h

Application: halls and corridors as well as above tables.
